Adapt to Extreme Temperatures
Consistent high efficiency in extreme temperatures with precise battery temperature compensation.
NEG-terminal design for Easy Installation
The all-in-one NEG-terminal design integrates the terminals for the solar panel array, starter battery and house battery, effectively saving installation space.
Comprehensive System Protections
This battery charger features multiple intelligent protections for batteries, solar panels, and the alternator, safeguarding your system and ensuring optimal charging.
Soft Start Circuit Design for Enhanced Battery Stability
The soft start circuit gradually increases the charger's input voltage, preventing sudden overvoltage and over-discharge.
Protect Your Solar Panels at Night
At night, the battery's voltage can exceed that of the solar panels, potentially causing reverse charging from the battery to the panels and leading to damage. Reverse current protection eliminates this risk, ensuring system safety.
Specifications
Terminal Size: M8 x 1.25 - 10mm
Terminal Range: 8AWG-4AWG
Communication Protocol: RS485
Operating Temperature Range: -31? to 149?/-35? to 65?
Storage Temperature Range: -40? to 176?/-40? to 80?
Humidity: 0%-95%, No Condensation
Maximum Operating Altitude: N/A
Dimensions: 9.61 x 5.75 x 3.78 inch/244 x 146 x 96mm
Weight: 4.10 lb / 1.86 kg
Certification: "CE;ROHS;FCC Part 15 class B; ETL listed to UL 1741 & CSA C22.2"
Warranty: 2-year material warranty
Protection: Reverse Polarity Protection/Overvoltage Protection/Over Discharge Protection/Overcurrent Protection/Over Temperature Protection/Overcurrent Protection
