Description
Utilizing the unparalleled efficiency of OSRAM's® finest OSLON® LED, the ST3K-40L offers market-leading performance with 40 LEDs. A unique 8 Flood + 24 Spot + 8 Flood reflector distribution creates a powerful 50° wide beam and 5.8° spot beam that reaches an astounding 1 lux at 699m. The True White 5700K Colour temperature provides stunning clarity and definition.
Its Pure-Drive™ circuit design directs 97% of input power straight to the LEDs. This bar is built to withstand the harsh conditions of the Australian outback, with a 100% Polyester UV and abrasion resistant powder coat that will never discolour. Equipped with a Pressure Equalization vent, it is protected against water, dust, and other contaminants. With an IP68 rating, it is dust and particle tight and can withstand being submerged in water up to 3 meters. The environmentally sealed Deutsch DT-2 connector ensures
Specifications
| LED |
40 x Osram Oslon White |
| Effective Lumen |
8,250Lm |
| Peak Intensity (Candela) |
486,400cd |
| Operating Voltage |
10-30V DC |
| IP Rating |
IP68 |
| Current Draw |
8.6A @ 13.6v
|
| Colour Temperature (CCT) |
5700 Kelvin |
| Housing Material |
Aluminium Extrusion & Cast |
| Lens |
GE™ Lexan |
| Mounting Bracket |
Powder Coated 3mm Stainless Steel |
| Bolts and FIttings |
3 Series Stainless Steel |
| Beam Type |
Flood Spot Combo |
| Life Span |
50,000 Hours |
| Weight |
3.475kg |
| Operating Environment |
-40 - +50° Celsius |
| PHOTOMETRIC DATA |
|
| 10 M |
4,886 Lx |
| 50 M |
195 Lx |
| 100 M |
46 Lx |
| 200 M |
11.5 Lx |
| 699 M |
1 Lx |
What's Included
- ST3K 41.5inch LED LIGHT BAR
- Stainless Fasteners
- Stainless Steel Side Mounting Brackets
- 12v Quick Fit to High Beam Wiring, Relay, Wiring Kit and On/Off Switch
- H4 and HB3 adapters included
- Wiring Instructions
